What is the limited approach boundary for a 480 volt circuit?

The limited approach boundary is a distance from the employee to an exposed energized circuit part within which a shock hazard exists. The typical nominal AC voltages that a maintenance person would be working on of 120, 208, 220, 240, 277, 380, and 480 all have a limited approach boundary of 42 inches.

Simply so, what is the limited approach boundary?

Limited Approach Boundary. NFPA 70 defines the limited approach boundary as a shock protection boundary to be crossed by only qualified persons (at a distance from a live part), which is not to be crossed by unqualified persons unless escorted by a qualified person.

Additionally, how do you find the limited boundary? The limited approach boundary is the minimum distance from the energized item where unqualified personnel may safely stand. No untrained personnel may approach any closer to the energized item than this boundary. The boundary is determined by NFPA 70E Table 2-1.3.

Also to know, what are the three limits of approach boundaries?

The NFPA 703® recognizes three arc flash boundary levels: the limited approach boundary, the restricted area, and the prohibited area boundary.

What is an electrical boundary?

The Arc Flash Boundary (AFB) is the distance from exposed, energized electrical components within which a person could receive a second degree burn if an electrical arc flash were to occur.

What is the limited approach boundary distance for an exposed fixed circuit?

Limited Approach Boundary – The Limited Approach Boundary (LAB) is identified as the “distance from an exposed energized electrical conductor or circuit part within which a shock hazard exists”. Best practice if for any unqualified person to stay 42” (3' 6”) or more away from the hazard.

What is flash protection boundary?

Flash Protection Boundary (outer boundary): The flash boundary is the farthest established boundary from the energy source. If an arc flash occurred, this boundary is where an employee would be exposed to a curable second degree burn (1.2 calories/cm2).

What is Arc Flash working distance?

Basically, the working distance is the distance between you and the point of origin of an arc flash. The point of origin for an arc flash will typically be inside a piece of electrical equipment, at an energized conductor or bus. A typical working distance for low voltage equipment might be 18 inches.

How is arc flash measured?

Arc flash heat energy is calculated at the worker's upper body (torso) and face. It is based on arc energy, the workers distance to the arc, and length of exposure. The arc energy at the worker's body is called the “incident energy” measured in cal/cm2 or J/cm2.

Which approach boundary is the closest to the exposed energized parts?

The Restricted Approach Boundary is the shock protection boundary closest to the exposed energized parts and may only be crossed by qualified electrical workers following safe electrical work-practices which include wearing appropriate shock protection PPE and using insulated tools.

What is hrc1?

NFPA 70E is a safety standard that denotes Hazard Risk Categories (HRC) based upon an array of occupational duties. An HRC level is determined by the minimum amount of calories per square centimeter (ATPV or Cal/cm2).

At what voltage does arc flash occur?

What is Arc Flash? Arc Flash is the result of a rapid release of energy due to an arcing fault between a phase bus bar and another phase bus bar, neutral or a ground. During an arc fault the air is the conductor. Arc faults are generally limited to systems where the bus voltage is in excess of 120 volts.

What is incident energy analysis?

Incident energy is a measure of thermal energy at a working distance from an arc fault. The unit of incident energy is cal/cm². Incident energy analysis is required for selecting arc rated Personal Protective Equipment (PPE) when work is performing at or near a potential source of an arc flash.

How far away from an arc flash can a person be fatally burned?

Dangers of Arc Flashes Fatal burns can occur when the victim is several feet from the arc. Serious burns are common at a distance of 10 feet. Staged tests have shown temperatures greater than 437°F (225°C) on the neck and hands of a person standing close to an arc blast.

What is a flash hazard analysis?

Flash hazard analysis: A method to determine the risk of personal injury as a result of exposure to incident energy from an electrical arc flash. Flash protection boundary: An approach limit at a distance from live parts that is un-insulated with which a person could receive a second-degree burn.

Which type of hazard control is most likely to eliminate hazards?

Elimination. Physically removed the hazard—is the most effective hazard control. For example, if employees must work high above the ground, the hazard can be eliminated by moving the piece they are working on to ground level to eliminate the need to work at heights.

What is an arc blast?

Blast: a destructive wave of highly compressed air spreading outward from an explosion. An arc blast is caused by the rapid expansion of air during an arc fault. This sudden expansion produces an intense pressure wave.

What best describes an arc flash?

An arc flash (also called a flashover) is the light and heat produced as part of an arc fault, a type of electrical explosion or discharge that results from a low-impedance connection through air to ground or another voltage phase in an electrical system.

What are the three types of shock boundaries?

There are three electrical shock hazard boundaries depending on the voltage of the appliance and termed the limited approach boundary, the restricted approach boundary, and the prohibited approach boundary.

What is an energized conductor?

Energized Work Tasks You are completing an energized electrical work task when there are exposed energized electrical conductors or circuit parts that you may approach and/or interact with that can expose you to an electric shock or create an arcing fault that results in an arc flash.
