How many amps does an electric trolling motor draw?
By Robert Clark |
To use an example, a 55 lb thrust motor unit has a peak power draw of 40 amps. If you use the trolling motor for 6 hours at average 50% load of 20 amps, the trolling motor will then require a battery load of 120 Ah. (6 hours X 20 amps=120 amp hours).
.
Besides, how many amps does a Minn Kota trolling motor draw?
Conductor Gauge and Circuit Breaker Sizing Table
| Motor Thrust / Model | Max Amp Draw | Circuit Breaker |
|---|---|---|
| 40 lb., 45 lb. | 42 | 50 Amp @ 12 VDC |
| 50 lb., 55 lb. | 50 | 60 Amp @ 12 VDC |
| 70 lb. | 42 | 50 Amp @ 24 VDC |
Also, how many amps does a Minn Kota 30 draw? While the Minn Kota Endura C2 30 Freshwater Transom Mounted Trolling Motor (30" Shaft) model takes 32 amps/hr to get that 30 lbs of thrust, this one can do 30 lbs of thrust for roughly 18 amps/hr. 40 to 45 lbs thrust is roughly 29 amps/hr instead of the 42 amps/hr that those respective motors draw for the same thrust.
Also, how much power does a trolling motor use?
Trolling motors are rated in pounds of thrust. As a rule of thumb 72 to 75lb. of thrust roughly equals one horsepower or 746W of electrical power. A typical 12V motor that draws 60A consumes approximately 720W.
How long will a 12v battery run a trolling motor?
(Just to keep the boat moving for slow drifts - musky or bass fishing). 6-8 hours seems reasonable with an older motor. Battery group size could play a role in life but on a 12v older power drive a 24 to 27 group battery running between 6-8 hours is in line with where you can expect yourself to be.
Related Question AnswersCan you use a car battery for a trolling motor?
A car battery is 12-volts and can power your trolling motor. However, the length of time you'll be able to do so will be a fraction of the time a designated deep cycle battery could do it, and the car battery will have a dramatically shorted lifespan if you choose to deep-cycle it for trolling applications.How long will a battery power a trolling motor?
If you use the trolling motor for 6 hours at average 50% load of 20 amps, the trolling motor will then require a battery load of 120 Ah. (6 hours X 20 amps=120 amp hours). A battery bank of a 240 Ah capacity rating selected as deep cycling should be kept to 50% to ensure maximum battery life.How fast will a 30 lb thrust trolling motor go?
In fact two 55 pound thrust motors will not move you any faster than one 30 pound thrust motor. Higher thrust 12V trolling motors are designed for bigger heavier boats with larger payloads. The maximum speed of a trolling motor is 5 mph regardless of how many pounds of thrust.What size wire do I need for a 24 volt trolling motor?
In most cases, the manufactures recommended wire is 8 gauge for most 24-volt systems and 6 gauge for a system of 20 feet or longer. To account for voltage-drop, heat and current changes resulting from low batteries I recommend 6 gauge wire and 4 gauge for over 15 feet.Do I need a circuit breaker on my trolling motor?
A trolling motor circuit breaker is designed to "trip" at a certain amperage, which breaks the circuit and prevents the motor from overloading and damaging itself. The exception are the MotorGuide Xi5 80 series, which require 60 amp circuit breakers.What size battery do I need for my Minn Kota trolling motor?
A Minn Kota trolling motor will operate with any lead acid, deep cycle marine 12-volt battery/batteries. For best results, use a deep cycle, marine battery with at least a 110-ampere hour rating.Can you run a trolling motor out of water?
Your motor is cooled by the water around it, while running it out of the water for a very short time would be OK, it would take a long time to drain the battery much running the motor out of the water with no load. Why risk damaging a very expensive TM to just drain the battery down.How much can you discharge a deep cycle battery?
Automotive batteries will generally fail after 30-150 deep cycles if deep cycled, while they may last for thousands of cycles in normal starting use (2-5% discharge). Deep cycle batteries are designed to be discharged down as much as 80% time after time and have much thicker plates.How long can you run a trolling motor on a battery?
The larger the rating, the more power the battery can hold, and the longer it will be able to power a motor at a given speed. For example, a 100 amperage hour battery is one that would be able to supply 25 amps of power for 4 hours (25 amps * 4 hours = 100 amp hours) before running out of energy.How many pounds of thrust do I need for a trolling motor?
Boat weight is the most important consideration to take into account when choosing a trolling motor. A beginning rule of thumb is that you want a minimum of 2 lbs of thrust for every 100lbs.How long will a 24 volt trolling motor last?
A typical grou 30 battery will supply 25 amps of current for about 2 hours. If you run your 24 volt trolling motot at maximum speed, you will be drawing about 25-30 amps from the batteries. This will give you maximum speed and power and is often necessary on a large boat, or in strong winds.How do you increase speed on a trolling motor?
To improve the speed of your boats using trolling motor you need to charge its batteries. If your batteries do not provide enough power then your boat cannot go faster. It might be due to old batteries which can affect the output. So you need to get them changed quickly and get new powerful batteries.How many amps does a 40 lb trolling motor use?
The Endura 40 is 42 Maximum Amp Draw that at 100% power. the Endura 45 and 50 also are 42 Max Amp Draw.How many amps does a 30lb trolling motor pull?
Because of the larger windings in the 50 lb thrust model, lower speeds use less amperage for the same thrust. While the Minn Kota Endura C2 30 Freshwater Transom Mounted Trolling Motor (30" Shaft) model takes 32 amps/hr to get that 30 lbs of thrust, this one can do 30 lbs of thrust for roughly 18 amps/hr.What size wire do I need for a trolling motor?
Conductor Gauge and Circuit Breaker Sizing Table| Motor Thrust / Model | Max Amp Draw | Wire Extension Length* |
|---|---|---|
| 10 feet | ||
| 30 lb. | 30 | 10 AWG |
| 40 lb., 45 lb. | 42 | 8 AWG |
| 50 lb., 55 lb. | 50 | 6 AWG |
